Flip Chip packaging ( 2 days)

This 2 day course provides an overview of Flip Chip Packaging.

Topics:

​History of Flip Chip

​

• Advantages of Flip Chip and comparison to alternative packaging options

• Types of Flip Chip and their advantages & disadvantages


• Solder bump

• Copper pillar bump

• Gold bump

• Stud bump & other


Bonding mechanisms and resulting joints

• Solder reflow (mass)

• Solder reflow (thermode)

• Thermocompression

• TCNCP (Thermo-Compression, Non-Conductive Paste)

• Conductive paste

• Bond hierarchy in multi-chip packages

• Other


Substrates for Flip Chip bonding

• Ceramic

• Laminate

• Leadframe

• Bond pad designs


• SMD

• NSMD

• Plated up

• Other


Design rules for Flip Chip

Chip

• I/O cell placement vs packaging requirements

• Substrate / package

• Cost implications

• DFT

• DFR


Manufacturing – process, materials, equipment

• Wafer prep including RDL

• Bumping process including UBM

• Evaporation, sputtering, plating, photolithography…

• Flip Chip assembly & process flow

• Underfill – including capillary, no-flow and other

• Equipment

• OSAT Flip Chip options

• Flip Chip Quality Control


Process control
Inspection
Equipment and metrology

Flip Chip Reliability

• TCE mismatch and DNP

• Role of underfill

• Reliability tests (T/C, drop, bend, high temperature bias, other)

• Electromigration of solder vs. copper pillar bump


Flip Chip thermal enhancement

• Modeling


Flip Chip electrical performance

• Versus wirebonding

• High speed issues

• Modeling


Flip Chip Application Examples

• High End / High Speed

• High Leadcount

• Mobile

• Analog / RF

• Flip Chip on chip

• Other


Flip Chip-Like Application Examples

• Stacked chip TSV microbumps

• TAB

• Display drivers

• 2.5D / interposers / EMIB


Flip Chip versus other packaging options

• Wirebond leadframe packaging

• Wirebond laminate packaging

• FOWLP / FOPLP

• SiP
